PDR4922 PBT Raw Material UV And Weather Resistance With Surface Finish

Product Categories

Polyamide PA12 [20]
PVC Raw Material [5]
PP Material [17]
PC Material [20]
PA6 Material [41]
PA66 Material [27]
PSU Material [3]
PPSU Material [3]
LCP Plastic Material [13]
PTFE Material [7]
PBT Plastic Material [13]
EVA Raw Material [12]
ABS Raw Material [12]
PMMA Raw Material [15]
PCTG Material [4]
POM Polyoxymethylene [13]
PA9T Material [5]
PES Polyethersulfone [5]
MBS Material [6]
Other Plastic Raw Materials [149]

Dongguan Pengchen New Materials Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

PDR4922 PBT Raw Material UV And Weather Resistance With Surface Finish

Name: PDR4922 PBT Raw Material UV And Weather Resistance With Surface Finish
Brand: foundation innovations
Price: 2.6 USD

Wholesale PDR4922 PBT Raw Material UV And Weather Resistance With Surface Finish from china suppliers

Brand Name : foundation innovations

Model Number : PBT PDR4922

Place of Origin : Schaber

MOQ : 25KG

Price : USD2.6-3KG

Payment Terms : T/T

Supply Ability : 500TONS

Delivery Time : 7-15

Packaging Details : Plastic bag/Paper bag

Certification : MSDS

Material : PBT PDR4922

Shape : Pellets

Process : Injection molding

HDT Unannealed 0.45MPa 3.2mm : 216

HDT Unannealed 1.8MPa 3.2mm : 184

HDT 1.8MPa 4.0mm : 170

Density : 1.4

Flexural Strength : 79 MPa

Ingredient : 100% Virgin Material

DELIVERY TIME : 5-14 Days

Port : ShenZhen/GuangZhou,China

Contact Now

Products Description

PDR4922 PBT Raw Material UV And Weather Resistance With Surface Finish

PBT Schaber Foundation Innovation PDR4922 Glass Fiber Reinforced Thermal Stability High Impact High Strength Automotive Parts

VLAOX PBT PDR4922 advantages
Customizable features High mechanical, thermal and electrical properties as well as excellent chemical resistance and dimensional stability;
Excellent chemical resistance Excellent resistance to a wide range of chemicals including hydrocarbons, dilute acids and bases, cleaning agents and most aqueous salt solutions; Versatility and regulatory compliance offers a wide range of fill and unfill levels with specified UL and other agency compliance levels. Health care level meets food contact and medical regulatory norms.

product feature

PBT
PDR4922
Product information
Part Marking Code	>PBT-GF<
Material Shape	Pellets
Process	Injection molding
FR	HB
Material Attribute	Glass Fiber Reinforced
specification	·UL
UL File NO.	E45587
Certificate	W
Physical property	Standard Value Unit
Density	ASTM D792	1.4	g/cm³
Density	ISO 1183	1.4	g/cm³
Shrinkage Flow 3.2mm	INTERNAL METHOD	0.16	%
Shrinkage xFlow 3.2mm	INTERNAL METHOD	0.94	%
Water Absorption 23℃ Saturation	ISO 62	0.03	%
Water Absorption 23℃50RH	ISO 62	0.03	%
Melt Index 250℃ 2.16kg	ASTM D1238	13.4	g/10min
Melt Index 250℃ 2.16kg Mechanical behavior	ISO 1133 Standard	12 Value	cm³/10min Unit
Tensile Modulus 50mm/min	ASTM D638	5410	MPa
Tensile Modulus 1.0mm/min	ISO 527	5230	MPa
Tensile Strength Yield 50mm/min Type I	ASTM D638	85	MPa
Tensile Strength Break 50mm/min Type I	ASTM D638	81	MPa
Tensile Strength Yield 50mm/min	ISO 527	85	MPa
Tensile Strength Break 50mm/min	ISO 527	81	MPa
Elongation Yield 50mm/min Type I	ASTM D638	2.4	%
Elongation Break 50mm/min Type I	ASTM D638	3.3	%
Elongation Yield 50mm/min	ISO 527	3	%
Elongation Break 50mm/min	ISO 527	3.6	%
Flexural Strength Yield 1.3mm/min	ASTM D790	133	MPa
Flexural Strength Yield 2.0mm/min	ISO 178	130	MPa
Flexural Modulus 1.3mm/min	ASTM D790	4580	MPa
Flexural Modulus 2.0mm/min	ISO 178	4860	MPa
Izod Notch Impact 23℃	ASTM D256	102	J/m
Izod Notch Impact -30℃	ASTM D256	58	J/m
Izod Notch Impact 23℃4.0mm Type A	ISO 180	10	kJ/m²
Izod Notch Impact -30℃4.0mm Type A	ISO 180	6	kJ/m²
Charpy Notch Impact 23℃ 1eA	ISO 179	8	kJ/m²
Instrumented Impact 23℃ Tota Energy	ASTM D3763	8	J
Thermal	Standard Value Unit
HDT Unannealed 0.45MPa 3.2mm	ASTM D648	216	℃
HDT Unannealed 1.8MPa 3.2mm	ASTM D648	184	℃
HDT 1.8MPa 4.0mm	ISO 75	170	℃
Vicat Softening Temperature 50℃/hr 50N	ASTM D1525	200	℃
Vicat Softening Temperature 50℃/hr 50N	ISO 306	195	℃
Vicat Softening Temperature 120C/hr 50N	ISO 306	196	℃
CLE Flow-40.0~40℃	ASTM E831	4.20E-5	cm/cm/℃
CLE xFlow-40.0~40℃	ASTM E831	1.14E-4	cm/cm/℃
CLE Flow -40.0~40℃	ISO11359	4.40E-5	cm/cm/℃
CLE xFlow-40.0~40℃	ISO 11359	1.18E-4	cm/cm/℃
Flammability	Standard	Value	Unit
Flame Rating All Color 0.75mm	UL94	HB
Flame Rating All Color 1.5mm	UL94	HB

Application

PDR4922 PBT Raw Material UV And Weather Resistance With Surface Finish

Optical lighting

It used to manufacture large lampshade, protective glass, left and right eyepiece tubes of Optical instrument, etc., and can also be widely used as transparent materials on aircraft.

Electronic appliances

It used in the manufacturing of insulation connectors, coil frames, sockets, insulation sleeves, telephone shells and parts, and battery shells for mining lamps, and so on.

Mechanical equipment

It used for manufacturing various gears, racks, worm gears, worms, bearings, cams, bolts, levers, crankshafts, ratchets, and can also be used as mechanical components such as shields

Physical Property Parameter

Company Profile:

Dongguan Pengchen plastic Co., LTD Was Established On November 15, 2022, Located Indongguan City.

The Company Covers An Area Of More Than 400 Square Meters, And The Three warehouses Cover A Total Area Of 110000 Square Meters, With 50-60 Employees.

Our Company Is An Expert In The Field Of Plastic Raw Materials. A Professional Supplier Of modified Engineering Plastics Raw Materials. Engaged In R&d, Production And Sales Of engineering Plastics.

We Provide High-quality Plastic Raw Materials With Low Order quantity, Reasonable Price And Fast Delivery.

our Product Range Includes Engineering Materials And General Mater

Warehouse:

FAQ

How about our package?

1.All the packing can be customized.

2.Plastic bags for inner packing, good quality moisture-proof bags for outer packing.

3.We generally make 25kgs per small bag by accurate weight, this will be very convenient for the customer using. It’s very easy to

handle the dosage.

What are our business principles?

1.For the trial order, 1tons will be acceptable.

2.We will do our best for the customer as long as you choosing us.

3.We promise to solve all the problems during trading process, our quality and the products will be approved by your side.

What are the advantages of our shipping and delivery?

1.We make sure all the products will be inspected strictly before loading.

2.We will make the shipment within 7 days after confirm the payment.

3.We will recommend the best suitable shipping company for our customer from different countries. Saving cost for our client

Application	Electronics electrical appliances mobile phones cars
Grade	Injection Grade,Extrusion Grade
OEM/ODM	Accepted
